Product range 01. Rolling Stock Cables UNIRAIL HT – EN 50382-2 1800 V 150°C - type F Single core unsheathed cable 14 UNIRAIL HT – EN 50382-2 1800 V 150°C - type FF Single core sheathed cable 15 UNIRAIL HT – EN 50382-2 3600 V 150°C - type F Single core unsheathed cable 16 UNIRAIL HT – EN 50382-2 3600 V 150°C - type FF Single core sheathed cable 17 UNIRAIL HT - EN 50382-2 600V 150°C - type FX Single core transparent cable 18 UNIRAIL HT – EN 50382-2 3600 V 150°C - type FX Single core sheathed cable 19 UNIRAIL HT - EN 50382-2 3600V 150°C - type FFS Single core screened cable with EMC performance 20 UNIRAIL S – EN 50264-3-1 600 V - type M Single core unsheathed cable 21 UNIRAIL S – EN 50264-3-1 1800 V – type M Single core unsheathed cable 22 UNIRAIL S – EN 50264-3-1 1800 V – type MM Single core sheathed cable 23 UNIRAIL S – EN 50264-3-1 1800 V – type MMS Single core screened sheathed cable 24 UNIRAIL S - EN 50264-3-1 3600 V - type MM Single core sheathed cable 25 UNIRAIL S - EN 50264-3-1 3600 V - type MMS Single core sheathed cable 26 UNIRAIL S – EN 50264-3-2 300 V – type MM Multicore unscreened cable 27 UNIRAIL S – EN 50264-3-2 300 V – type MMS Multicore screened cable 28 UNIRAIL S – EN 50264-3-2 600 V – type MM Multicore unscreened cable 29 UNIRAIL S – EN 50264-3-2 600 V – type MMS Multicore screened cable 30 UNIRAIL S – EN 50264-3-2 300 V – type MM – EN 50200 Multicore cable, fire resistant 31 UNIRAIL S – EN 50264-3-2 300 V – type MMS – EN 50200 Multicore screened cable, fire resistant 32 UNIRAIL S – EN 50264-3-1 600 V – type M – EN 50200 Single core unsheathed cable, fire resistant 33 UNIRAIL S – EN 50264-3-2 600 V – type MM – EN 50200 Multicore cable, fire resistant 34 UNIRAIL S – EN 50264-3-2 600 V – type MMS – EN 50200 Multicore screened cable, fire resistant 35 UNIRAIL P – EN 50264-3-2 300 V – type MM Multicore unscreened cable 36 UNIRAIL P – EN 50264-3-2 300 V – type MMS Multicore screened cable 38 UNIRAIL P – EN 50264-3-2 300 V – type MM Multipair unscreened cable 40 UNIRAIL P – EN 50264-3-2 300 V – type MMS Multipair screened cable 41 UNIRAIL P – EN 50264-3-2 300 V – type MMS Multicore hybrid screened cable 42 UNIRAIL TW – EN 50306-2 300 V – type M Single core cable 43 UNIRAIL TW – EN 50306-3 300 V – type MMS Single core and multicore cables, screened and thin wall sheathed 44 UNIRAIL TW – EN 50306-4 300 V – type MM (Table 1) Multicore unscreened cables, standard wall sheathed 45 UNIRAIL TW – EN 50306-4 300 V – type MMS (Table 3) Multicore screened cables, standard wall sheathed 46 UNIRAIL TW – EN 50306-4 300 V – type MMS (Table 5) Multipair cables, individually screened and sheathed and with an overall sheath 47 UNIRAIL TW – EN 50306-4 300 V – type MMS (Table 7) Multipair cables with an overall screen and sheath 48 UNIRAIL D – ETHERNET CABLE CATEGORY 5e 50 UNIRAIL D – ETHERNET CABLE CATEGORY 5e FIRE RESISTANT 54 UNIRAIL D – ETHERNET CABLE CATEGORY 6 56 UNIRAIL D – ETHERNET CABLE CATEGORY 7A 58 UNIRAIL D – RS485 and BUS cables 60 UNIRAIL D - MVB and WTB cables 67 UNIRAIL J - JUMPER cables 69 02. Mass Transit Cables Single and multicore signalling PVC cables for RFI installations 74 Multicore signalling halogen-free cables for outdoor installations according to RFI specifications 75 Single and multicore signalling halogen-free cables for internal installations according o RFI specifications 78 Single and multicore, halogen-free power cables for outdoor installations according to RFI specifications 80 Single and multicore, halogen-free, fire resistant, power cables for outdoor installations according to RFI specifications 81 12 72 TYPE DESCRIPTION PAG. www.unika.it Visit our website
01 Rolling Stock Cables 12
UNIRAIL HT – EN 50382-2 1800 V 150°C - type F Single core unsheathed cable 14 UNIRAIL HT – EN 50382-2 1800 V 150°C - type FF Single core sheathed cable 15 UNIRAIL HT – EN 50382-2 3600 V 150°C - type F Single core unsheathed cable 16 UNIRAIL HT – EN 50382-2 3600 V 150°C - type FF Single core sheathed cable 17 UNIRAIL HT - EN 50382-2 600V 150°C - type FX Single core transparent cable 18 UNIRAIL HT – EN 50382-2 3600 V 150°C - type FX Single core sheathed cable 19 UNIRAIL HT - EN 50382-2 3600V 150°C - type FFS Single core screened cable with EMC performance 20 UNIRAIL S – EN 50264-3-1 600 V - type M Single core unsheathed cable 21 UNIRAIL S – EN 50264-3-1 1800 V – type M Single core unsheathed cable 22 UNIRAIL S – EN 50264-3-1 1800 V – type MM Single core sheathed cable 23 UNIRAIL S – EN 50264-3-1 1800 V – type MMS Single core screened sheathed cable 24 UNIRAIL S - EN 50264-3-1 3600 V - type MM Single core sheathed cable 25 UNIRAIL S - EN 50264-3-1 3600 V - type MMS Single core sheathed cable 26 UNIRAIL S – EN 50264-3-2 300 V – type MM Multicore unscreened cable 27 UNIRAIL S – EN 50264-3-2 300 V – type MMS Multicore screened cable 28 UNIRAIL S – EN 50264-3-2 600 V – type MM Multicore unscreened cable 29 UNIRAIL S – EN 50264-3-2 600 V – type MMS Multicore screened cable 30 UNIRAIL S – EN 50264-3-2 300 V – type MM – EN 50200 Multicore cable, fire resistant 31 UNIRAIL S – EN 50264-3-2 300 V – type MMS – EN 50200 Multicore screened cable, fire resistant 32 UNIRAIL S – EN 50264-3-1 600 V – type M – EN 50200 Single core unsheathed cable, fire resistant 33 UNIRAIL S – EN 50264-3-2 600 V – type MM – EN 50200 Multicore cable, fire resistant 34 UNIRAIL S – EN 50264-3-2 600 V – type MMS – EN 50200 Multicore screened cable, fire resistant 35 UNIRAIL P – EN 50264-3-2 300 V – type MM Multicore unscreened cable 36 UNIRAIL P – EN 50264-3-2 300 V – type MMS Multicore screened cable 38 UNIRAIL P – EN 50264-3-2 300 V – type MM Multipair unscreened cable 40 UNIRAIL P – EN 50264-3-2 300 V – type MMS Multipair screened cable 41 UNIRAIL P – EN 50264-3-2 300 V – type MMS Multicore hybrid screened cable 42 UNIRAIL TW – EN 50306-2 300 V – type M Single core cable 43 UNIRAIL TW – EN 50306-3 300 V – type MMS Single core and multicore cables, screened and thin wall sheathed 44 UNIRAIL TW – EN 50306-4 300 V – type MM (Table 1) Multicore unscreened cables, standard wall sheathed 45 UNIRAIL TW – EN 50306-4 300 V – type MMS (Table 3) Multicore screened cables, standard wall sheathed 46 UNIRAIL TW – EN 50306-4 300 V – type MMS (Table 5) Multipair cables, individually screened and sheathed and with an overall sheath 47 UNIRAIL TW – EN 50306-4 300 V – type MMS (Table 7) Multipair cables with an overall screen and sheath 48 UNIRAIL D – ETHERNET CABLE CATEGORY 5e 50 UNIRAIL D – ETHERNET CABLE CATEGORY 5e FIRE RESISTANT 54 UNIRAIL D – ETHERNET CABLE CATEGORY 6 56 UNIRAIL D – ETHERNET CABLE CATEGORY 7A 58 UNIRAIL D – RS485 and BUS cables 60 UNIRAIL D - MVB and WTB cables 67 UNIRAIL J - JUMPER cables 69 13
Item n° Cross-section [mm²] Diameter without braid [mm] Cable mass [kg/km] RA801 1,5 6,3 ÷ 7,3 57 RA802 2,5 6,7 ÷ 7,8 69 RA803 4 7,2 ÷ 8,4 86 RA804 6 7,7 ÷ 9,0 107 RA805 10 8,5 ÷ 10,0 151 RA806 16 9,6 ÷ 11,2 219 RA807 25 10,9 ÷ 12,7 305 RA808 35 12,1 ÷ 14,1 394 RA809 50 13,5 ÷ 15,8 540 RA810 70 15,2 ÷ 17,8 725 RA811 95 17,0 ÷ 19,9 961 RA812 120 18,6 ÷ 21,7 1182 RA813 150 20,1 ÷ 23,5 1438 RA814 185 21,7 ÷ 25,4 1760 RA815 240 24,1 ÷ 28,2 2249 RA816 300 26,4 ÷ 30,9 2680 RA817 400 29,9 ÷ 34,9 3450 UNIKA (Italy) - EN 50382-2 1800 V 16 F 150°C - code UNIRAIL HT – EN 50382-2 1800 V 150°C - type F CONSTRUCTION Type: single core unsheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Screening separator: semiconductive black tape Insulation: silicon rubber compound, type EI111 according to Standard EN 50382-1, colour black if not otherwise stated Textile braid: available upon request Marking: UNIKA (Italy) – EN 50382-2 1800V cross-section F 150°C – WW/ YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) TECHNICAL DATA Temperature rating up to and including 150°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, acids and alkali Enhanced abrasion and tear resistance and enhanced thermal aging for long term (beyond 20000h at 170°C) according to the TRENITALIA specification and principal OEMs requests Bending radius: fixed ≥3 outer diameter, flexible ≥ 5 outer diameter Range of approval: According to table 1 (cross-section 1,5 ÷ 400 mm²) of EN 50382-2 for cables rated 1800V (see IMQ test certificate) The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 14 UNIKA - ROLLING STOCK CABLES - UNIRAIL HT – EN 50382-2 1800 V 150°C - type F
TDS 00/2025 UNIRAIL HT – EN 50382-2 1800 V 150°C - type FF Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RAA01 1,5 6,8 ÷ 7,9 63 RAA02 2,5 7,2 ÷ 8,4 76 RAA03 4 7,7 ÷ 9,0 93 RAA04 6 8,2 ÷ 9,6 115 RAA05 10 9,4 ÷ 11,0 168 RAA06 16 10,5 ÷ 12,2 236 RAA07 25 12,3 ÷ 14,4 339 RAA08 35 13,6 ÷ 15,9 432 RAA09 50 15,0 ÷ 17,5 583 RAA10 70 16,8 ÷ 19,7 780 RAA11 95 19,0 ÷ 22,2 1039 RAA12 120 20,8 ÷ 24,3 1276 RAA13 150 22,3 ÷ 26,1 1539 RAA14 185 24,5 ÷ 28,6 1871 RAA15 240 27,1 ÷ 31,7 2417 RAA16 300 29,5 ÷ 34,6 2760 RAA17 400 33,2 ÷ 38,9 3620 UNIKA (Italy) - EN 50382-2 1800 V 25 FF 150°C - code TECHNICAL DATA Temperature rating up to and including 150°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, acids and alkali Enhanced abrasion and tear resistance and enhanced thermal aging for long term (beyond 20000h at 170°C) according to the TRENITALIA specification and principal OEMs requests Bending radius: fixed ≥3 outer diameter, flexible ≥ 5 outer diameter Range of approval: According to table 2 (cross-section 1,5 ÷ 400 mm²) of EN 50382-2 for cables rated 1800V (see IMQ test certificate) CONSTRUCTION Type: single core sheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Screening separator: semiconductive black tape Insulation: silicon rubber compound, type EI111 according to Standard EN 50382-1, colour white if not otherwise stated Tape (optional): polyester or other non-hygroscopic tape Sheath: silicon rubber compound, type EM107 according to Standard EN 50382-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50382-2 1800V cross-section FF 150°C – WW/ YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. UNIKA - ROLLING STOCK CABLES -UNIRAIL HT - EN 50382-2 1800 V 150°C - type FF Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 15
UNIRAIL HT – EN 50382-2 3600 V 150°C - type F Item n° Cross-section [mm²] Diameter without braid [mm] Cable mass [kg/km] RA901 2,5 7,6 ÷ 8,9 84 RA902 4 8,1 ÷ 9,5 102 RA903 6 9,0 ÷ 10,6 124 RA904 10 9,5 ÷ 11,1 170 RA905 16 10,5 ÷ 12,3 241 RA906 25 11,8 ÷ 13,8 329 RA907 35 13,0 ÷ 15,2 422 RA908 50 14,4 ÷ 16,9 571 RA909 70 16,1 ÷ 18,9 760 RA910 95 17,5 ÷ 20,5 984 RA911 120 19,3 ÷ 22,6 1216 RA912 150 20,8 ÷ 24,4 1474 RA913 185 22,6 ÷ 26,5 1810 RA914 240 25,4 ÷ 29,8 2326 RA915 300 27,7 ÷ 32,4 2780 RA916 400 30,8 ÷ 36,0 3610 UNIKA (Italy) - EN 50382-2 3600 V 10 F 150°C - code TECHNICAL DATA Temperature rating up to and including 150°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, acids and alkali Enhanced abrasion and tear resistance and enhanced thermal aging for long term (beyond 20000h at 170°C) according to the TRENITALIA specification and principal OEMs requests Bending radius: fixed ≥3 outer diameter, flexible ≥ 5 outer diameter Range of approval: According to table 3 (cross-section 2,5 ÷ 400 mm²) of EN 50382-2 for cables rated 3600V (see IMQ test certificate) CONSTRUCTION Type: single core unsheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Screening separator: semiconductive black tape Insulation: silicon rubber compound, type EI111 according to Standard EN 50382-1, colour black if not otherwise stated Textile braid: available upon request Marking: UNIKA (Italy) – EN 50382-2 3600V cross-section F 150°C – WW/ YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 16 UNIKA - ROLLING STOCK CABLES - UNIRAIL HT – EN 50382-2 3600 V 150°C - type F
UNIRAIL HT – EN 50382-2 3600 V 150°C - type FF Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RAB01 2,5 9,9 ÷ 11,6 122 RAB02 4 10,4 ÷ 12,2 143 RAB03 6 10,9 ÷ 12,8 167 RAB04 10 11,8 ÷ 13,8 217 RAB05 16 12,8 ÷ 15,0 291 RAB06 25 14,7 ÷ 17,2 403 RAB07 35 15,9 ÷ 18,6 503 RAB08 50 17,5 ÷ 20,5 668 RAB09 70 19,2 ÷ 22,4 867 RAB10 95 20,8 ÷ 24,3 1110 RAB11 120 22,4 ÷ 26,2 1343 RAB12 150 24,1 ÷ 28,2 1621 RAB13 185 26,4 ÷ 30,9 2004 RAB14 240 29,4 ÷ 34,4 2555 RAB15 300 31,7 ÷ 37,1 3070 RAB16 400 35,0 ÷ 40,9 3970 UNIKA (Italy) - EN 50382-2 3600 V 50 FF 150°C - code TECHNICAL DATA Temperature rating up to and including 150°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, acids and alkali Enhanced abrasion and tear resistance and enhanced thermal aging for long term (beyond 20000h at 170°C) according to the TRENITALIA specification and principal OEMs requests Bending radius: fixed ≥3 outer diameter, flexible ≥ 5 outer diameter Range of approval: According to table 5 (cross-section 2,5 ÷ 400 mm²) of EN 50382-2 for cables rated 3600V (see IMQ test certificate) CONSTRUCTION Type: single core sheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Screening separator: semiconductive black tape Insulation: silicon rubber compound, type EI111 according to Standard EN 50382-1, colour white if not otherwise stated Tape (optional): polyester or other non-hygroscopic tape Sheath: silicon rubber compound, type EM107 according to Standard EN 50382-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50382-2 3600V cross-section FF 150°C – WW/ YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 17 UNIKA - ROLLING STOCK CABLES - UNIRAIL HT – EN 50382-2 3600 V 150°C - type FF
UNIRAIL HT – EN 50382-2 600 V 150°C - type FX Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RAD00* 0,60 2,6 12 RAD06 16 10,1 220 RAD07 25 10,7 280 RAD08 35 12,1 410 RAD09 50 13,8 540 RAD10 70 15,6 770 RAD11 95 17,0 975 RAD12 120 18,5 1220 RAD13 150 20,6 1460 RAD14 185 25,5 2240 UNIKA (Italy) - EN 50382-2 600 V 70 FX 150°C - code TECHNICAL DATA Temperature rating up to and including 150°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, acids and alkali Enhanced abrasion and tear resistance and enhanced thermal aging for long term (beyond 20000h at 170°C) according to the TRENITALIA specification and principal OEMs requests Bending radius: fixed ≥3 outer diameter, flexible ≥ 5 outer diameter Range of approval: In compliance with EN 50382-2 (see IMQ test certificate) CONSTRUCTION Type: single core transparent cable Conductor: tinned copper conductor according to class 6 EN 60228 for section ≥ 16 mm², class 5 for section < 16 mm² Tape (optional): polyester or other non-hygroscopic transparent tape Insulation: silicon rubber compound, type EI111 according to Standard EN 50382-1, transparent or other colour Marking: UNIKA (Italy) – EN 50382-2 600V cross-section FX 150°C – WW/ YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Cables are suitable for flexible installations (e.g. Jumper cables) The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 18 UNIKA - ROLLING STOCK CABLES - UNIRAIL HT - EN 50382-2 600 V 150°C - type FX
UNIRAIL HT – EN 50382-2 3600 V 150°C - type FX Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RA907X* 35 13,0 ÷ 15,2 465 RA908X 50 15,2 ÷ 17,8 580 RA909X 70 16,9 ÷ 19,8 770 RA910X 95 18,3 ÷ 21,4 995 RA911X 120 20,1 ÷ 23,5 1240 RA912X 150 21,6 ÷ 25,3 1485 RA913X 185 23,4 ÷ 27,4 1830 RA914X 240 26,2 ÷ 27,4 2400 UNIKA (Italy) - EN 50382-2 3600 V 70 FX 150°C - code TECHNICAL DATA Temperature rating up to and including 150°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, acids and alkali Enhanced abrasion and tear resistance and enhanced thermal aging for long term (beyond 20000h at 170°C) according to the TRENITALIA specification and principal OEMs requests Bending radius: fixed ≥3 outer diameter, flexible ≥ 5 outer diameter Range of approval: According to table 4 (cross-section 50 ÷ 185 mm²) of EN 50382-2 for cables rated 3600V (see IMQ test certificate) CONSTRUCTION Type: single core unsheathed cable Conductor: tinned copper conductor according to class 6 EN 60228 Screening separator: semiconductive black tape Insulation: silicon rubber compound, type EI111 according to Standard EN 50382-1, colour black if not otherwise stated Textile braid: available upon request Marking: UNIKA (Italy) – EN 50382-2 3600V cross-section FX 150°C – WW/ YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Cables are suitable for flexible installations (e.g. Jumper cables) * Out of the scope of the standard UNIKA - ROLLING STOCK CABLES - UNIRAIL HT - EN 50382-2 3600 V 150°C - type FX The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 19
UNIRAIL HT – EN 50382-2 3600 V 150°C - type FFS TECHNICAL DATA Temperature rating up to and including 150°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, acids and alkali Enhanced abrasion and tear resistance and enhanced thermal aging for long term (beyond 20000h at 170°C) according to the TRENITALIA specification and principal OEMs requests Bending radius: fixed ≥3 outer diameter, flexible ≥ 5 outer diameter Range of approval: In compliance with table 5 (cross-section 2,5 ÷ 400 mm²) of EN 50382-2 for cables rated 3600V (see IMQ test certificate) CONSTRUCTION Type: single core screened cable with EMC performance Conductor: tinned copper conductor according to class 5 EN 60228 Screening separator: semiconductive black tape Insulation: silicon rubber compound, type EI111 according to Standard EN 50382-1, colour white if not otherwise stated Tape (optional): polyester or other non-hygroscopic tape Screen: tinned copper wire braid with optional non-hygroscopic tape, minimum coverage 85% Sheath: silicon rubber compound, type EM107 according to Standard EN 50382-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50382-2 3600V cross-section FFS 150°C – WW/ YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) UNIKA (Italy) - EN 50382-2 3600 V 50 FFS 150°C - code Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RAC05 16 12,8 ÷ 15,0 370 RAC06 25 14,7 ÷ 17,2 485 RAC07 35 15,9 ÷ 18,6 580 RAC08 50 17,5 ÷ 20,5 750 RAC09 70 19,2 ÷ 22,4 1010 RAC10 95 20,8 ÷ 24,3 1200 RAC11 120 22,4 ÷ 26,2 1485 RAC11H 120 26,5 ÷ 30,0 1620 RAC12 150 24,1 ÷ 28,2 1770 RAC13 185 26,4 ÷ 30,9 2160 RAC14 240 29,4 ÷ 34,4 2720 Add letter C after the item number to have spiral tinned copper wire instead of braid The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 20 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-1 600 V - type M
UNIRAIL S – EN 50264-3-1 600 V - type M Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RB001 1 2,4 ÷ 2,8 14 RB002 1,5 2,8 ÷ 3,3 20 RB003 2,5 3,2 ÷ 3,8 29 RB004 4 3,8 ÷ 4,4 43 RB005 6 4,2 ÷ 5,0 63 RB006 10 5,1 ÷ 5,9 104 RB007 16 6,1 ÷ 7,2 157 RB008 25 7,8 ÷ 9,1 253 RB009 35 9,0 ÷ 10,6 336 RB010 50 10,6 ÷ 12,4 486 RB011 70 12,5 ÷ 14,6 673 RB012 95 13,9 ÷ 16,3 892 RB013 120 15,7 ÷ 18,4 1124 RB014 150 17,6 ÷ 20,6 1399 RB015 185 19,6 ÷ 22,9 1745 RB016 240 22,2 ÷ 26,0 2261 RB017 300 24,6 ÷ 28,8 2776 RB018 400 28,1 ÷ 32,9 3795 UNIKA (Italy) - EN 50264-3-1 600 V 16 M - code TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, fuels, oils, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: According to table 1 (cross-section 1 ÷ 400 mm²) of EN 50264-3-1 for cables rated 600V (see IMQ test certificate) CONSTRUCTION Type: single core unsheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape (optional): coloured tape for cross-section ≥ 16 mm² Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black or yellow-green if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-1 600V cross-section M – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Add the following letter after the item number for colours different from black G: yellow/green Y: grey B: blue R: red W: brown H: white J: yellow A: orange Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RB019 0,50 2,2 10 RB020 0,75 2,4 13 Out of the scope of the Standard. The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 21 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-1 600 V - type M
UNIRAIL S – EN 50264-3-1 1800 V – type M Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RB101 1,5 5,3 ÷ 6,2 47 RB102 2,5 5,7 ÷ 6,7 58 RB103 4 6,2 ÷ 7,3 75 RB104 6 6,7 ÷ 7,8 97 RB105 10 7,5 ÷ 8,8 144 RB106 16 8,6 ÷ 10,0 201 RB107 25 9,9 ÷ 11,6 298 RB108 35 11,1 ÷ 13,0 386 RB109 50 12,5 ÷ 14,6 534 RB110 70 14,2 ÷ 16,6 717 RB111 95 16,0 ÷ 18,7 953 RB112 120 17,6 ÷ 20,6 1177 RB113 150 19,1 ÷ 22,3 1433 RB114 185 20,9 ÷ 24,4 1777 RB115 240 23,7 ÷ 27,5 2272 RB116 300 25,6 ÷ 30,1 2785 RB117 400 29,2÷ 34,2 3840 UNIKA (Italy) - EN 50264-3-1 1800 V 35 M - code TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, fuels, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: According to table 2 (cross-section 1,5 ÷ 400 mm²) of EN 50264-3-1 for cables rated 1800V (see IMQ test certificate) CONSTRUCTION Type: single core unsheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape (optional): coloured tape for cross-section ≥ 16 mm² Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black or yellow-green if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-1 1800V cross-section M – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Add the following letter after the item number for colours different from black G: yellow/green Y: grey B: blue R: red W: brown H: white X: class 6 conductor A: orange Out of the scope of the Standard. Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RB118 0,50 5,0 35 RB120 0,75 5,2 40 RB119 1,0 5,4 45 The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 22 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-1 1800 V – type M
UNIRAIL S – EN 50264-3-1 1800 V – type MM CONSTRUCTION Type: single core sheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape (optional): coloured tape for cross-section ≥ 16 mm² Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black if not otherwise stated (upon request compound type EI110) Tape (optional): or talcum powder for strippability Sheath: crosslinked compound, type EM104 according to Standard EN 50264-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-1 1800V cross-section MM – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RB201 1,5 5,7 ÷ 6,7 49 RB202 2,5 6,0 ÷ 7,0 61 RB203 4 6,5 ÷ 7,6 78 RB204 6 7,0 ÷ 8,1 100 RB205 10 8,2 ÷ 9,6 156 RB206 16 9,2 ÷ 10,8 215 RB207 25 11,5 ÷ 13,4 343 RB208 35 12,7 ÷ 14,9 436 RB209 50 14,1 ÷ 16,5 591 RB210 70 15,8 ÷ 18,5 781 RB211 95 18,0 ÷ 21,0 1045 RB212 120 19,6 ÷ 22,9 1278 RB213 150 21,4 ÷ 25,1 1564 RB214 185 23,4 ÷ 27,4 1923 RB215 240 25,9 ÷ 30,3 2434 RB216 300 28,1 ÷ 32,9 2940 RB217 400 32,0 ÷ 37,4 3980 UNIKA (Italy) - EN 50264-3-1 1800 V 70 MMS - code TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, fuels, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: According to table 3 (cross-section 1,5 ÷ 400 mm²) of EN 50264-3-1 for cables rated 1800V (see IMQ test certificate) The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 23 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-1 1800 V – type MM
UNIKA (Italy) - EN 50264-3-1 1800 V 70 MMS - code The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 24 UNIRAIL S – EN 50264-3-1 1800 V – type MMS Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RCA07 25 13,0 ÷ 15,2 440 RCA08 35 14,5 ÷ 16,7 550 RCA09 50 15,3 ÷ 17,5 675 RCA10 70 17,0 ÷ 19,2 910 RCA11 95 19,2 ÷ 22,0 1180 TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, fuels, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: In compliance with EN 50264-3-1 for cables rated 1800V (see IMQ test certificate) CONSTRUCTION Type: single core sheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape (optional): coloured tape for cross-section ≥ 16 mm² Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black if not otherwise stated (upon request compound type EI110) Tape: non-hygroscopic tape on the assembly Screen: tinned copper wire braid with optional non-hygroscopic tape Sheath: crosslinked compound, type EM104 according to Standard EN 50264-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-1 1800V cross-section MMS – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-1 1800 V – type MMS
UNIRAIL S – EN 50264-3-1 3600 V - type MM Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RB301 2,5 8,6 ÷ 10,1 113 RB302 4 9,1 ÷ 10,7 134 RB303 6 9,6 ÷ 11,2 158 RB304 10 10,4 ÷ 12,2 210 RB305 16 11,5 ÷ 13,4 272 RB306 25 13,7 ÷ 16,1 416 RB307 35 14,9 ÷ 17,5 517 RB308 50 16,4 ÷ 19,1 680 RB309 70 18,0 ÷ 21,1 880 RB310 95 19,5 ÷ 22,8 1120 RB311 120 21,4 ÷ 25,1 1376 RB312 150 22,9 ÷ 26,8 1646 RB313 185 25,1 ÷ 29,4 2034 RB314 240 28,3 ÷ 33,1 2608 RB315 300 30,6 ÷ 35,8 3128 RB316 400 33,7 ÷ 39,4 4205 UNIKA (Italy) - EN 50264-3-1 3600 V 95 MMS - code TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, fuels, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: According to table 4 (cross-section 2,5 ÷ 400 mm²) of EN 50264-3-1 for cables rated 3600V (see IMQ test certificate) CONSTRUCTION Type: single core sheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape: semiconductive tape to reduce partial discharge effect Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black if not otherwise stated (upon request compound type EI110) Tape (optional): or talcum powder for strippability Sheath: crosslinked compound, type EM104 according to Standard EN 50264-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-1 3600V cross-section MM – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 25 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-1 3600 V – type MM
UNIRAIL S – EN 50264-3-1 3600 V - type MMS TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, fuels, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: According to table 4 (cross-section 2,5 ÷ 400 mm²) of EN 50264-3-1 for cables rated 3600V (see IMQ test certificate) CONSTRUCTION Type: single core sheathed cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape: semiconductive tape to reduce partial discharge effect Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black if not otherwise stated (upon request compound type EI110) Tape (optional): or talcum powder for strippability Sheath: crosslinked compound, type EM104 according to Standard EN 50264-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-1 3600V cross-section MMS – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Item n° Cross-section [mm²] Diameter [mm] Cable mass [kg/km] RC906 25 14,8 ÷ 16,5 510 RC907 35 16,1 ÷ 18,0 615 RC908 50 17,5 ÷ 19,5 770 RC909 70 19,1 ÷ 21,5 1030 RC910 95 21,1 ÷ 23,5 1210 RC911 120 23,0 ÷ 25,5 1550 RC912 150 25,0 ÷ 28,0 1840 RC913 185 27,0 ÷ 30,0 2260 RC914 240 30,5 ÷ 33,5 2850 UNIKA (Italy) - EN 50264-3-1 3600 V 95 MMS - code The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 26 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-1 3600 V – type MMS
UNIRAIL S – EN 50264-3-2 300 V – type MM Item n° Crosssection [mm²] Diameter [mm] Cable mass [kg/km] RB401 2x1 5,3 ÷ 6,2 42 RB425 3x1 5,7 ÷ 6,9 58 RB402 4x1 6,1 ÷ 7,2 67 RB426 5x1 6,9 ÷ 8,1 95 RB403 7x1 7,5 ÷ 8,7 111 RB428 8x1 8,5 ÷ 9,7 140 RB404 9x1 9,1 ÷ 10,6 150 RB427 10x1 9,8 ÷ 11,2 170 RB405 12x1 9,8 ÷ 11,5 180 RB433 16x1 11,6÷ 12,4 268 RB436 18x1 12,3÷ 13,1 303 RB406 19x1 11,7 ÷ 13,7 278 RB407 24x1 14,1 ÷ 16,5 363 RB408 32x1 15,5 ÷ 18,2 468 RB409 37x1 16,1 ÷ 18,9 530 RB410 40x1 16,7 ÷ 19,6 572 RB411 4x1,5 7,3 ÷ 8,6 94 RB434 5x1,5 9,0 ÷ 9,8 168 Item n° Crosssection [mm²] Diameter [mm] Cable mass [kg/km] RB412 7x1,5 8,7 ÷ 10,2 153 RB429 8x1,5 9,8 ÷ 11,0 190 RB413 9x1,5 10,9 ÷ 12,7 197 RB414 12x1,5 11,8 ÷ 13,8 257 RB415 19x1,5 14,2 ÷ 16,6 402 RB416 24x1,5 16,6 ÷ 19,5 503 RB417 32x1,5 18,7 ÷ 21,9 674 RB418 37x1,5 19,5 ÷ 22,8 761 RB437 3x2,5 7,6 ÷ 8,4 122 RB419 4x2,5 8,3 ÷ 9,8 138 RB420 7x2,5 10,2 ÷ 11,9 232 RB421 9x2,5 12,9 ÷ 15,1 309 RB422 12x2,5 13,9 ÷ 16,3 396 RB423 19x2,5 16,3 ÷ 19,1 601 RB424 24x2,5 19,6 ÷ 22,9 776 RB430 2x1,5 6,7 70 RB431 6x1,5 9,3 150 RB432 2x2,5 7,5 96 2 1 UNIKA (Italy) – EN 50264-3-2 300 V 3x1 MMG - code TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, fuels, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: According to table 1 (cross-section 1 ÷ 2,5 mm²) of EN 50264-3-2 for cables rated 300V (see IMQ test certificate) CONSTRUCTION Type: multicore unscreened cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape (optional): coloured tape Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black with numbers with or without yellow-green if not otherwise stated (upon request compound type EI110) Tape: non-hygroscopic tape on the assembly Sheath: crosslinked compound, type EM104 according to Standard EN 50264-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-2 300V (core number x cross-section) MM (MMG with yellow-green) – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Add letter G after the item number for cables with yellow/green conductor The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 27 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-2 300 V – type MM
UNIRAIL S – EN 50264-3-2 300 V – type MMS UNIKA (Italy) – EN 50264-3-2 300 V 4x2,5 MMS - code 2 2 3 3 1 4 1 TECHNICAL DATA Temperature rating up to and including 90°C Very low temperatures resistance (-40°C) Resistance to ozone, oils, fuels, acids and alkali Bending radius: refer to EN 50343 table 16 Range of approval: According to table 2 (cross-section 1 ÷ 2,5 mm²) of EN 50264-3-2 for cables rated 300V (see IMQ test certificate) CONSTRUCTION Type: multicore screened cable Conductor: tinned copper conductor according to class 5 EN 60228 Tape (optional): coloured tape Insulation: crosslinked compound, type EI109 according to Standard EN 50264-1, colour black with numbers with or without yellow-green if not otherwise stated (upon request compound type EI110) Tape: non-hygroscopic tape on the assembly Screen: tinned copper wire braid with optional non-hygroscopic tape Sheath: crosslinked compound, type EM104 according to Standard EN 50264-1, colour black if not otherwise stated Marking: UNIKA (Italy) – EN 50264-3-2 300V (core number x cross-section) MMS – WW/YYYY - traceability code Fire safety: hazard level HL3 according to Standard EN 45545-2 for indoor cables (EL1A) and outdoor cables (EL1B) Item n° Crosssection [mm²] Diameter [mm] Cable mass [kg/km] RB501 2x1 6,0 ÷ 7,1 60 RB525 3x1 6,5 ÷ 7,5 86 RB502 4x1 7,0 ÷ 8,2 94 RB530 6x1 8,1÷ 8,9 168 RB503 7x1 8,2 ÷ 9,6 137 RB526 8x1 9,4 ÷ 10,6 185 RB504 9x1 10,2 ÷ 11,9 195 RB505 12x1 10,9 ÷ 12,7 238 RB506 19x1 13,2 ÷ 15,4 368 RB507 24x1 15,2 ÷ 17,8 461 RB508 32x1 16,6 ÷ 19,4 578 RB509 37x1 17,2 ÷ 20,1 642 RB510 40x1 18,2 ÷ 21,3 710 RB511 4x1,5 8,0 ÷ 9,4 119 RB512 7x1,5 9,6 ÷ 11,3 199 RB527 8x1,5 10,4 ÷ 12,4 245 Item n° Crosssection [mm²] Diameter [mm] Cable mass [kg/km] RB513 9x1,5 12,1 ÷ 14,2 260 RB532 10x1,5 13,1 ÷ 13,9 323 RB514 12x1,5 13,0 ÷ 15,2 324 RB515 19x1,5 15,3 ÷ 17,9 498 RB516 24x1,5 18,1 ÷ 21,2 620 RB517 32x1,5 19,8 ÷ 23,2 803 RB518 37x1,5 20,5 ÷ 24,0 891 RB531 2x2,5 8,3 ÷ 9,1 133 RB519 4x2,5 9,2 ÷ 10,8 180 RB520 7x2,5 11,1 ÷ 13,0 285 RB521 9x2,5 13,9 ÷ 16,3 393 RB522 12x2,5 15,0 ÷ 17,5 488 RB523 19x2,5 17,8 ÷ 20,8 708 RB524 24x2,5 20,6 ÷ 24,1 905 RB528 2x1,5 7,3 101 RB529 3x1,5 7,8 116 Add letter G after the item number for cables with yellow/green conductor The characteristics of the products, described in the data sheet, do not constitute any contractual binding. UNIKA spa reserves the right to change the specifications without any notice. Partial or total reproduction of this document is forbidden. TDS 00/2025 Unless otherwise specified, all values are nominal, other values can be provided on request. The images are made for the sole purpose of illustrating the product and are purely indicative. 28 UNIKA - ROLLING STOCK CABLES - UNIRAIL S – EN 50264-3-2 300 V – type MMS
